Powercraft ECP-LED4 LED RANGE

Our ECP-LED Conversion kit is suitable for a wide range of LED fittings

AC LED Load
Suitable for a wide range of AC LED Tube, Down lights.
Short-circuit protection at battery terminals.
Extra low standby power consumption.
Able to power a LED light fitting at a reduce luminous flux for two hours or more
High temperature 70°C Li-Ion battery
Automatically activated in the event of power cuts
Offer a good luminous flux to facilitate the evacuation.

Technical Specifications

Model No

:

ECP-LED4

Mode of Operation

:

Maintend / Non-Maintained

Lamp

:

AC LED Tube 180-240 Volts AC, 22W (max)

Rated Duration

:

1 Hour / 2 Hours

Mains Supply

:

220-240 Volts, 50-60Hz

Power Consumption

:

3W

Battery

:

High Temperature Li-ion (LiPoFe4)

Charger

:

Regulated variable rate

Charge Monitor

:

LED

Test Facility

:

Momentary test switch

Supply Current

:

30mA

Safety Features

:

Low battery voltage cut off to prevent over discharge

Max Casing Temp, Tc

:

70°C

Max Ambient, Ta

:

50°C

Fitting Construction

:

Electro-galvanised steel

Standards / Compliance

:

-

Deskripsi

ECP-LED4
